PUSH-BUTTON DALI DL2-TK1L

DALI-2 1-channel push-button switch for flush mounting. Length 59mm, width 33mm, depth 15mm. DALI-2 certified. DALI-2 is the latest generation of the DALI standard, featuring an extended range of functions. DALI-2 devices include all previous DALI functions and are thus backward compatible. Compact DALI-2 control module with one 230V AC switching input. DL2-TK1L receives power from the DALI bus, so no separate power supply is required. Switching connection to DALI connectors is polarity-independent. Galvanic isolation between the switching input and the DALI interface. Multimaster feature: multiple modules can be installed on the same DALI line. Integrated DALI-2 application controller. Individual DALI commands, dimming range, and switching functions can be configured for each input. In addition to standard DALI commands, the application controller enables DALI DT8: TunableWhite and RGB(W) control as well as macros. The module includes a DALI-2 instance (push-button type, compliant with IEC62386-301), easy to integrate. Supports short press, long press (for dimming repetition), and switch operation. Suitable not only for push buttons but also for switches. Alternatively, for push-button functionality, a second function can be assigned to each input and activated/deactivated via a DALI bus scene/state command. Configurable "power-on behavior". DL2-TK1L receives power from the DALI bus, so no separate power supply is required. Switching connections to DALI connectors are polarity-independent. Application and operation: DL2-TK1L functions as a universal module for controlling DALI-compatible lighting. The switching input's operation can be individually configured. Like other Lunatone control devices, settings can be made using the DALI Cockpit software tool. Fundamentally, the application controller and DALI-2 instances are separated. The application controller directs direct DALI control commands that DALI drivers execute immediately. DALI-2 instances generate event messages interpreted and further processed by higher-level control units (WAGO, Beckhoff, LUNATONE DALI-2 KNX Gateway). Application controllers and instances can be active simultaneously. Factory delivery: Upon delivery, the basic configuration is already set (factory settings). It can be modified and customized as needed for each specific application. This product description is an automated translation of the original Finnish description.
