BUS CABLE KNX TG019 2X2X0.8MM2 500M

Technical Presentation of Hager's KNX Bus Cables Application: For use in bus systems (EIB - European Installation Bus/KNX - Konnex) and as an ICA cable for power supply installations. Suitable for installation on or in stairwells, even in damp and wet areas. Not approved for use as a power supply cable or for earth cable installations. Fire performance class: ECA Structure Conductors: Copper, solid, bare Core insulation: PVC or preferably halogen-free compound Core twisting: Four conductors twisted in a star formation Screen: Plastic tape Shielding: Plastic-laminated aluminum foil, drain wire Sheath: PVC (J-Y(St)Yh) or halogen-free compound (J-H(St)Hh); color: green RAL 6017 Electrical Properties - (Conductor) loop resistance max. 73.2 Ω/km - Insulation resistance min. 100 MΩ x km - Pair capacitance max. 100 nF/km - Unbalanced capacitance C1 max. 200 pF/100 m - Instantaneous operating voltage 300 V - Test voltage conductor - sheath 4 kV 50 Hz 1 min. - Thermal and mechanical properties - Temperature range in fixed installation -30 °C ... +70 °C - Cable diameter 6.2 ± 0.2 mm - Cable weight approx. 64 kg/km - Copper content 21 kg/km - Bending radius at least 7.5 x diameter This product description is an automated translation of the original Finnish description.
