BUS COULING UNIT KNX 800040001 KNX-PB (X1)
Product code
2803894
Bus application unit (TP+EASY)
Bus coupling unit for panel mounting, connecting the application module to the bus cable. Installation generally in panels with a 60 mm mounting pitch, bus connection via red-black teleplug. Mounting of the product on a mounting plate or with integrated clips, connection terminal for an external temperature sensor. Commissioning with ETS4 or ETS5 or easy application. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Bus coupler for bus system (EC000634)
Bus system KNXyes
Bus system KNX-RF (Radio Frequency)no
Bus system radio frequencyno
Bus system LONno
Bus system Powernetno
Other bus systemsNone
Radio frequency bidirectionalno
Mounting methodFlush-mounted
Width in number of modular spacings0
Number of connections sensor/actuator4
Type of fasteningMounting with claw and screw
Min. depth of built-in installation box32 mm
Product codes
SAPCDC153
STK2803894
PLC2803894
GTIN/EAN3250617153362
Manufacturer part number80040001
Vendor material number2803894
Basic information
Package measurements (L x W x H)32 x 71 x 71 mm
Package volume0.161 l
Package weight0.05 kg
Base uniteach
Package units1 / 100 / 100
Package contents–
UNSPSC39121524
BrandHAGER
VendorUTU OY
Documents (7)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.0069
GWP, uniteach
Source for GWP dataEPD
