OCCUPANCY/MOTION DETECTOR KNX TXD501 360D 4CH IP41 FM WHITE

Motion and presence sensor for automatic on/off control and constant light level adjustment of lighting in various smaller rooms, office spaces, and work areas based on lighting level and movement. Master-slave operation enabled via programming object for communication between connected sensors.

Operating mode can be activated using a dedicated remote control or via ETS software. The detection area has a diameter of approximately 10 m for motion detection and approximately 5 m for presence detection in the central area at an installation height of 2.5 m with a 360° detection angle. The detection area can be restricted using masking stickers supplied with the sensor. The lighting turn-off delay is adjustable between 5 s and 60 min.

Installation into the ceiling, recessed into the ceiling surface, with an installation opening diameter of 50-54 mm. The sensor is equipped with a KNX bus interface for integration into a KNX building automation system.

This product description is an automated translation of the original Finnish description.
