RADIO PUSH BUTTON KNX Q.1/Q.3 4F BAT 3V QUICKLINK ALU

KNX radio button, 4-channel quicklink Number of radio channels: 4 Radio transmission/reception frequency: 868.3 MHz Radio transmission power: < 10 mW Radio protocol: KNX Radio Number of quicklink connections: max. 20 transmitters/receivers Radio transmission range (inside building): max. 30 m Radio transmission range (free field): max. 100 m Transmission duty cycle: 1 % Receiver class: 2 Operating temperature: -5 ... +45 °C Extended operating options for a 1-piece housing with two additional, freely definable radio channels. Manual or remote control via Quicklink radio control - Naturally low energy requirement - Functions for button operating areas up/down or right/left can be assigned to control connected loads as receiver and curtain remote control as transmitter - Transmission and/or reception behavior definable - Zero function (factory settings) - Quicklink functions: switching, dimming, curtain, 2 states, switch-off delay, button, closing contact - ETS additional functions: +6 states, 1 button control up/down, operating state on/off, dimming value, brightness display, button, state indication, forced control, priority - Operating areas can be defined as single or dual area operation - State storage lockable - LED display for compatibility of application module/housing - Learning and operating LEDs - Switch-on brightness level definable for each operating area with light controller housing, voltage-independent, storeable - Tool-free quicklink learning using buttons and LED display - Learning and operating button - Detachment protection with separate screw - Connection to KNX twisted pair system using KNX radio media coupler This product description is an automated translation of the original Finnish description.
