FLOODLIGHT FLOODLIGHT PFM FL200 IP66 20000LM 840 SY ML B

Product code
4529946
FLOODLIGHT SYM GEN4 - the luminaires in this product family are equipped with the Multi Lumen feature, allowing the luminous flux to be easily selected from the luminaire itself. The new generation luminaires are also equipped with a breath vent valve and a new tighter penetration grommet that prevent moisture from forming inside the luminaire.

Key technical specifications:
  • Luminous flux: 17500 / 20000 lm
  • Color temperature: 4000 K, CRI80
  • Power: 117 / 133 W
  • Luminous efficacy: 150 lm/W
  • Beam angle: symmetrical 100 x 100 D
  • Dimmable: No
  • Dimensions (Length/Width/Height): 294 x 58 x 376 mm
  • Weight: 3.476 kg
  • Protection rating: IP66 and IK08
  • Average service life: 100 000 hours (L70/B50 +25 C)
  • Average service life: 70 000 hours (L80/B10 +25 C)
  • Operating temperature: -30…+50 C
  • Warranty: 5 years
  • Certifications: CE, ENEC, D-mark
Fixed 1 meter long pre-stripped connection cable integrated into the luminaire. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingyes
Suitable for built-in mountingno
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingno
Suitable for traverse mountingno
Suitable for pedestal/floor mountingyes
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilitySwivelling
With movement sensorno
With light sensorno
Lamp typeLED not exchangeable
With light sourceyes

Product codes

SAPDFL324
STK4529946
PLC4529946
GTIN/EAN4099854306402
Manufacturer part number4099854306402
Vendor material number4529946

Basic information

Package measurements (L x W x H)75 x 324 x 415 mm
Package volume10.13 l
Package weight3.68 kg
Base uniteach
Package units1 / 2 / 28 / 56
Package contents
UNSPSC39111611
BrandLEDVANCE
VendorLEDVANCE OY

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)27.0563
GWP, uniteach
Source for GWP dataEPD

Documents (1)

Sustainability brochures & documents

Manufacturer

NameLEDVANCE GmbH
Postal addressParkring 1-5, 85748, Garching near Munich, Germany
