SHOWER MIXER ORAS 7471 NOVA 3/4 THERMOSTAT

Oras Nova

The Oras Nova product family's thermostatic shower taps offer simple, modern design suitable for all types of bathrooms and shower sets. The thermostatic tap maintains a consistent water temperature in the shower, even if the hot water temperature fluctuates. The thermostatic tap responds to changes in water temperature by adjusting the outgoing water to the set temperature, enhancing user comfort. Oras Nova shower taps feature ergonomic handles, a safety temperature limiter, and a thermally insulated surface.

Oras Nova 7471

The Oras Nova 7471 is a thermostatic shower tap with cross-connected hot and cold water supplies. The temperature control handle includes a temperature limiter that enhances safety and environmental friendliness by preventing accidental delivery of excessively hot water. The limiter can be bypassed via a button on the handle. The tap's environmental friendliness is further enhanced by the EcoFlow flow regulator. The shower tap includes dirt traps and check valves.

Features

• operating pressure: 100–1000 kPa
• EcoFlow rate at 300 kPa: 0.19 l/s
• flow rate at 300 kPa: 0.27 l/s
• pressure loss at flow rate (0.2 l/s): 165 kPa
• hot water: max. +80 °C
• noise class: I (ISO 3822) Oras lab.
• STF certificate: STF VTT-RTH-00085-17
• connection size: G3/4
• connection type: reversed cold/hot water connection
• handle type: temperature control handle, flow control handle
• installation width: cc 150 mm
• material: brass
• finish: chrome
• type approved

Maintenance and Care

The Oras Nova 7471 shower tap should be cleaned regularly using a cleaning agent with a sponge or cloth. A neutral or slightly alkaline cleaning agent is recommended. Direct spraying of cleaning agent onto the tap is not recommended; always use a soft sponge or cloth as an auxiliary tool. Proper cleaning maintains the tap's surface finish and internal components, extending its service life.

All adjustments and maintenance for Oras taps can be performed at the installation site.

Replacement Parts

Available replacement parts for the Oras Nova 7471 shower tap:

• flow control handle: LVI 6420571
• operating valve: LVI 6421506
• dirt traps, DN15: 6422063
• sealing washer: LVI 6422179
• temperature control handle: LVI 6420572
• O-ring set: LVI 6421003
• thermostatic control unit: LVI 6421004

A comprehensive selection of Oras replacement parts and other tap ranges is available from Onninen's online store and Express outlets, worth exploring.

This product description is an automated translation of the original Finnish description.
