WASH BASIN MIXER INSPERA ORAS 3016F

Oras Inspera 3016F

Oras Inspera 3016F is a touch-free sink faucet with a lever for temperature control. The automatic faucet is conveniently activated without contact, and the temperature can be adjusted as needed by turning the lever. The temperature can also be limited, making the faucet both ecological and safe to use. The electronic faucet operates on a battery, and the pulse-controlled magnetic valve ensures a long service life. The sink faucet includes strainers and check valves.

Features

• operating pressure: 100–1000 kPa
• flow rate at 300 kPa (with flow restrictors): 0.2 l/s
• pressure loss at flow rate (0.1 l/s): 200 kPa
• after-flow time: 3 s (1–20 s)
• automatic flush: off (off/1–120 h)
• automatic flush duration: 30 s (1–1800 s)
• max. flow time: 2 min (1–1800 s)
• hot water: max. +70 °C
• connection size: G3/8
• projection: 138 mm
• protection class: IP55
• battery: Lithium 2CR5 6 V
• sound class: I (ISO 3822)
• EMC directive: 2014/30/EU
• KIWA SE: 1606
• spout type: fixed spout
• material: brass
• color: chrome
• type-approved

Installation

Installing and commissioning Oras faucets is easy. Oras has developed the innovative 3S-Installation mounting system for Oras faucets, which simplifies and accelerates faucet installation. The mounting system includes a mounting component and a flexible installation key. The 3S-Installation system reduces the time required for faucet installation and thus increases work efficiency.

The Oras Inspera 3016F sink faucet features flexible connection hoses that facilitate installation. When installing these hoses, ensure they are not bent with too small a radius to allow unrestricted water flow through the hose. Installation of the sink faucet is easy thanks to the faucet’s Autofocus sensor. Thanks to the sensor, no adjustment of the faucet is required during installation.

Maintenance and Care

The Oras Inspera 3016F sink faucet should be cleaned regularly with a cleaning agent and a sponge or cloth. A suitable cleaning agent is neutral or slightly alkaline. Direct spraying of the cleaning agent onto the faucet is not recommended; always use a soft sponge or cloth as an auxiliary tool. Proper cleaning maintains the surface and internal components of the faucet and extends its service life.

The Oras Inspera 3016F sink faucet operates on a lithium battery. The battery should be replaced when the charge level becomes low. The electronic faucet has a low battery indicator. Typical battery life is approximately 2–4 years. Only lithium batteries should be used in Oras faucets, as alkaline batteries are unsuitable due to their characteristics.

All adjustments and maintenance for Oras faucets can be performed at the faucet’s installation location. Monitoring and changing settings for the Oras Inspera 3016F sink faucet can be conveniently done via Bluetooth connection.

Replacement Parts

A wide range of replacement parts is available for Oras faucets. Oras guarantees the availability of replacement parts for its faucets for 10 years from the date of manufacture.

Available replacement parts for the Oras Inspera 3016F sink faucet:

• temperature control lever: LVI 6420647
• diaphragm support ring: LVI 6422170
• magnetic valve: LVI 6422171
• sensor, 6/9/12 V Bluetooth: LVI 6420643
• < This product description is an automated translation of the original Finnish description.
