WASHBASIN FAUCET ORAS 9362FZ 3 V, BT, SMART BIDETTA

Oras Electra Safety 9362FZ is a touch-free faucet with a temperature control handle and a remotely operable Smart Bidetta hand shower. The aerator has an adjustable flow angle of ±10°. Intelligent sensor technology via Bluetooth enables easy monitoring of faucet usage and adjustment of settings through a separate app. Integrated water temperature measurement prevents the risk of scalding from hot water. The faucet has a brass body and features a simple and fast 3S mounting system. The faucet is battery-powered at 3 V, convertible to mains voltage at 9 V. A mains power cable (L=650 mm) is included with the faucet. The faucet includes strainers, check valves, and flexible connection hoses. Features

• aerator type: aerator with flow limiter, adjustable flow angle
• connection type: flexible connection hoses
• electronic components: Advanced PSD sensor, indicator light for functions, low battery indicator
• hand shower type: remotely operable Smart Bidetta
• shower components: hand shower, shower holder, shower hose (1500 mm)
• special features: inner body made of zinc-resistant brass, 3S-Installation mounting system
• spout type: fixed spout
• color: chrome
• after-flow time: 3 s (1-20 s)
• automatic flush: off (off/1-120 h)
• automatic flush duration: 30 s (1-1800 s)
• max. flow time: 2 min (1 - 1800 s)
• flow rate at 300 kPa (with flow limiter): 0.09 l/s
• pressure loss at flow rate (0.1 l/s): 375 kPa
• backflow prevention (EN1717): EB
• connection size: G3/8
• hot water: max. +70 °C
• material: brass
• projection: 124 mm
• operating pressure: 100 - 1000 kPa
• battery: AA 1.5 V Lithium x 2, CR 2450 3 V
• Bluetooth version: 5.x (D060576)
• electrical connection: 9 V
• EU directives: Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU
• EN standard: ETSI EN 301 489-1 V1.9.2, ETSI EN 300 328 v2.2.2, EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011+AC:2012, EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
• sound class: I (ISO 3822)
• protection class: IP 55

Replacement Parts

• aerator, M24x1 uk (Chrome): LVI 6420619
• window: Oras 1014281V
• complete magnetic valve, 3 V: LVI 6420325
• sensor, 6/12 V, Bluetooth (Chrome): Oras 1015155V
• temperature control: Oras 1000580V
• temperature control handle (Chrome): Oras 1016155V
• cover cap (Chrome): Oras 1015252V
