WASHBASIN MIXER ORAS 1015F-106SAFIRA ECO
Product code
6110360
Oras Safira Eco 1015F-106 faucet features an aerator and a swivel spout with 120° rotation (can be limited to 40°-80°). A flow restrictor (6 l/min) enables low water consumption. The faucet meets the requirements for efficient water use set by Green Building. The faucet has flexible supply hoses.
Features- aerator type: fixed aerator
- connection type: flexible supply hoses
- lever/handle type: single operating lever/handle with hot/cold symbols
- mechanical parts: ř 40 mm control unit
- special features: 3S-Installation mounting system
- spout type: swivel spout
- color: chrome
- temperature controls: temperature and flow rate limitation capability
- flow rate at 300 kPa (with flow restrictor): 0.1 l/s
- pressure loss at flow rate (0.1 l/s): 200 kPa
- backflow prevention (EN1717): AA
- connection size: G3/8
- hot water: max. +70 °C
- material: brass
- projection: 133 mm
- operating pressure: 50 - 1000 kPa
- noise class: I (ISO 3822)
- operating lever: LVI 6420625
- protective cap: LVI 6420632
- locking nut: LVI 6420331
- control unit, Green Building: LVI 6420733
- control unit: LVI 6420301
- spout, L=132: LVI 6510237
- spout restrictor, 40°-80°: LVI 6420574
- spout restrictor, 120°: LVI 6420642
- mounting screw, M8x1, L=130: LVI 6420637
- mounting kit: LVI 6420634
- aerator, M24x1, 6 l/min: LVI 6420721
- aerator, M24x1 STD HC A: LVI 6421630
- bearing ring: LVI 6420620
- X-sealing pack: LVI 6420263
- bearing ring: LVI 6420348
- base seal: LVI 6420646
- support plate, 100x60mm: LVI 6420134
- nut: LVI 6420241
Product details
Technical specifications
Product class (ETIM)Washbasin mixing tap (EC011328)
ModelMechanical
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlOther
Material tapBrass
Surface protectionChromium-plated
Surface treatmentPolished
Basic colourChrome
Accent colourChrome
MountingTop/tap hole
Number of tap holes1-hole
Connection supplyHose (gland nut)
Connection size supply3/8 inch (10)
Spout modelRotating, bottom
Product codes
SAPCPQ178
HPAC6110360
PLC6110360
GTIN/EAN6414150099113
Manufacturer part number1015F-106
Vendor material number6110360
Basic information
Package measurements (L x W x H)590 x 290 x 65 mm
Package volume11.122 l
Package weight2.02 kg
Base uniteach
Package units1 / 10 / 40 / 120
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
Documents (11)
Environment and safety
Sustainability categories
Circular economy
Water saving
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)6
Type ApprovalYes
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)11.9988
GWP, uniteach
Source for GWP dataEPD
