WASHBASIN MIXER ORAS 9220FZ-104 ELECTRA 3 V ECO BT

Oras Electra ECO+ 9220FZ-104 is a touch-free faucet with a temperature control handle. Intelligent sensor technology with Bluetooth connectivity enables easy monitoring of faucet usage and adjustment of settings via a dedicated app. The faucet features a composite structure and a simple and fast 3S mounting system. Battery-powered with 3 V, convertible to 9 V mains power using, for example, adapter 199550 or adapter 290007. The faucet comes with a mains power cable (L=650 mm). It includes strainers, check valves, and flexible supply hoses. The faucet can be connected to the Oras Digital Services platform. A flow restrictor (3.4 l/min) enables low water consumption. The faucet meets the requirements for efficient water use set by Green Building.

• spout type: aerator with flow restrictor, adjustable flow angle
• connection type: flexible supply hoses
• electronic components: advanced PSD sensor, status indicator lights, low battery indicator
• handle type: temperature control handle
• mechanical components: mixing valve for manual temperature adjustment, check valves, strainers
• special features: 3S Installation mounting system, software settings adjustable via Oras App (Bluetooth)
• spout type: fixed spout
• color: chrome
• temperature controls: temperature limit stop (retrofit), intelligent hot water safety function
• after-flow time: 3 s (1-20 s)
• automatic flush: off (off/1-120 h)
• automatic flush duration: 30 s (1-1800 s)
• max. flow time: 2 min (1 - 1800 s)
• flow rate at 300 kPa (with flow restrictor): 0.057 l/s
• backflow prevention (EN1717): EB
• connection size: G3/8
• hot water: max. +70 °C
• material: composite
• projection: 117 mm
• operating pressure: 100 - 1000 kPa
• battery: AA 1.5 V Lithium x 2
• Bluetooth version: 5.x (D060576)
• electrical connection: 9 V
• EU directives: Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU
• EN standard: EN 15091, ETSI EN 301 489-1 V1.9.2, ETSI EN 300 328 v2.2.2, EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011+AC:2012, EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
• sound class: I (ISO 3822)
• protection class: IP 55

• aerator, M24x1, -105: LVI 6510075
• aerator, M24x1, -104: LVI 6420700
• pilot valve: LVI 6420811
• sensor, 3/9 V, Bluetooth: LVI 6420814
• temperature control unit: LVI 6420818
• temperature control handle (chrome): LVI 64208 This product description is an automated translation of the original Finnish description.
