WASHBASIN MIXER SAFIRA ORAS 1008F
Product code
6110329
Oras Safira 1008F washbasin faucet features a Bidetta hand shower, bracket, and 1.75 m hose. The faucet has a poppet valve, aerator, fixed spout, and flexible supply hoses.
Features- aerator type: fixed aerator
- connection type: flexible supply hoses
- extensions: poppet valve
- hand shower type: Bidetta hand shower
- lever/handle type: single operating lever/handle, hot/cold symbols
- mechanical parts: ř 40 mm control unit
- shower components: shower holder, shower hose (1750 mm)
- special features: 3S-Installation mounting system
- spout type: fixed spout
- color: chrome
- temperature controls: temperature and flow rate limitation capability
- flow rate at 300 kPa: 0.13 l/s
- pressure loss at flow rate (0.1 l/s): 160 kPa
- backflow prevention (EN1717): HC
- connection size: G3/8
- warm water: max. +70 °C
- material: brass
- projection: 107 mm
- operating pressure: 50 - 1000 kPa
- noise class: I (ISO 3822) Oras lab.
- Sintef: Sintef No. 3638
- STF certificate: EUFI29-22005194-TH
- KIWA SE: 1490
- O-ring, 32.7x3: LVI 6420449
- poppet valve plug (Chrome): LVI 6420440
- cellular rubber seal (10 pcs), 60/40x5: LVI 6420459
- molded seal, D60xD44: LVI 6420451
- lift rod, Safira (Chrome): LVI 6420636
- lift rod (Satin): LVI 6510147
- lift rod, L=380 (Chrome): LVI 6420445
- lift rod, Ventura (Chrome): LVI 6420162
- lift rod, Vienda (Chrome): LVI 6420295
- lift rod, L=400 (Chrome): LVI 6420161
- swivel joint (Chrome): LVI 6420444
- poppet valve lever (Chrome): LVI 6420447
- operating lever: LVI 6420625
- protective cap: LVI 6420635
- locking nut: LVI 6420331
- control unit: LVI 6420301
- mounting screw, M8x1, L=130: LVI 6420637
- mounting kit: LVI 6420634
- aerator, M24x1 STD HC A: LVI 6421630
- base seal: LVI 6420646
- nut: LVI 6420241
- holder: LVI 6420746
- plug This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Washbasin mixing tap (EC011328)
ModelMechanical
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlOther
Material tapBrass
Surface protectionChromium-plated
Surface treatmentPolished
Basic colourChrome
Accent colourChrome
MountingTop/tap hole
Number of tap holes1-hole
Connection supplyHose (gland nut)
Connection size supply3/8 inch (10)
Spout modelFixed, bottom
Product codes
SAPCER004
HPAC6110329
PLC6110329
GTIN/EAN6414150077739
Manufacturer part number1008F
Vendor material number6110329
Basic information
Package measurements (L x W x H)585 x 225 x 95 mm
Package volume12.504 l
Package weight2.033 kg
Base uniteach
Package units1 / 4 / 16 / 80
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
The country of origin stated by the supplierFinland
Documents (8)
Certificates
Brochures & documents
Links
Environment and safety
Sustainability categories
Circular economy
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)7.8
Type ApprovalYes
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)12.076
GWP, uniteach
Source for GWP dataEPD
