WALL/CEILING LUMINAIRE FRAME ROUND MAXI 3K SEN WH
Product code
4522812
Frame is a modern and stylish lighting series suitable for both indoor and outdoor use. Can be mounted on ceiling or wall. Made from die-cast, powder-coated aluminum with black, white or graphite finish. The lamp shade is made of opal UV-stabilized polycarbonate. Frame series features round, square and rectangular designs in multiple sizes. Available with motion sensor, dusk-to-dawn sensor and emergency lighting version. Easy to install. Two cable entries and exits providing also surface mounting option. 10-year corrosion protection warranty, IP65, IK10. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingno
Suitable for light line configurationno
Suitable for clamp-mountingno
With mounting materialyes
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialAluminium
Surface protection housingOther
Product codes
SAPCFZ017
STK4522812
PLC4522812
GTIN/EAN7021986051445
Manufacturer part number605144
Vendor material number4522812
Basic information
Package measurements (L x W x H)332 x 332 x 92 mm
Package volume10.141 l
Package weight3.1 kg
Base uniteach
Package units1
Package contents–
UNSPSC39111605
BrandSG ARMATUREN
VendorSG ARMATUREN OY
Documents (6)
Brochures & documents
Links
Environment and safety
Manufacturer
NameSG Armaturen AS
Postal addressSkytterheia 25, 4790 Lillesand, Norway
