PRESENCE DETECTOR KNX LUXA 103 S360-12 UP

Presence detector designed for recessed ceiling installation in indoor spaces. The detector features a 360° circular detection area with a diameter of 12 m (113 m²) at a mounting height of 3 m. Compatible with KNX bus system, featuring 2 light channels and 2 presence channels for HVAC control. The detector provides automatic lighting control with continuous dimming or switching mode, and dimmable lighting in switching mode with or without daylight influence.

Features

• 2 light channels and 1 light measurement
• Integrated temperature sensor
• Day/night switching via electrical message
• Standby function (directional light)
• 3 logic channels (AND/OR/XOR KNX Data-Secure)
• Full or partial automatic operation possible
• Manual override possible via external KNX buttons
• Unidirectional brightness measurement (mixed light measurement)
• Simple brightness measurement adjustment
• Short-term presence detection
• Adjustable control speed
• Teach-in function
• Display function
• Locking functions
• Switching delay and presence monitoring time adjustable
• Expansion of detection area via parallel connection
• Sensitivity can be adjusted for outdoor use
• Test mode for verifying operation and detection area
• Configuration via ETS software (all functions configurable via remote control/app or app (BLE))

This product description is an automated translation of the original Finnish description.
