PRESENCE DETECTOR KNX THERONDA S360 FLAT DE WH

Product code
2807065
Passive infrared occupancy sensor for ceiling mounting, circular detection area 360°, max. Ø 9 m (64 m²), automatic lighting control based on movement and ambient light, dual-light measurement suitable for fluorescent lamps (FL/PL/ESL), halogen/incandescent lamps, and LED lamps, lighting channel A: relay, 230 V, fully automatic operation, adjustable light level switching threshold, teach-in function, pulse function for stairwell automation, adjustable after-run time, adjustable detection sensitivity, test mode for verifying operation and detection area, ready for immediate use thanks to factory settings (light level switching threshold 300 lux, after-run time 10 minutes), changes to values and settings require one of these optional remote controls: control remote SendoPro, maintenance remote theSenda P, user remote theSenda This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Movement sensor for bus system (EC001582)
Bus system KNXyes
Bus system KNX-RF (Radio Frequency)no
Bus system radio frequencyno
Bus system LONno
Bus system Powernetno
Radio frequency bidirectionalno
ModelPresence detector
Mounting methodFlush-mounted
Suitable for ceiling mountingyes
Suitable for wall mountingno
MaterialPlastic
Material qualityThermoplastic
Surface protectionUntreated
Surface finishingMatt
ColourWhite

Product codes

SAPDFR215
STK2807065
PLC2807065
GTIN/EAN7612748006416
Manufacturer part number2089560
Vendor material number2807065

Basic information

Package measurements (L x W x H)150 x 100 x 80 mm
Package volume1.2 l
Package weight0.225 kg
Base uniteach
Package units1
Package contents
UNSPSC46171608
BrandTHEBEN
VendorTHEBEN OY

Environment and safety

Manufacturer

NameTheben AG
Postal addressHohenbergstrasse 32, 72401 Haigerloch, Germany
