METERING CENTRE LUJA M250YLI.0 50A IP34 FE

Sturdy measurement centers are manufactured from galvanized steel and powder-coated light gray. They are type-tested and certified according to European standards by SGS Fimko Oy. All Vohek centers are manufactured in Finland. Features

• Rated voltage of the center: Un = Ui 400 V (50 Hz)
• Enclosure rating: IP34
• Protection class: I
• Distribution system: TN-
• Short-time rated withstand current: Icw < 10 kA
• EMC operating environments A and B
• Weight: 19.5 kg
• Color: RAL 7035
• Main switch does not disconnect voltage from the meter
• Sealing capability for main fuses
• Surge protection level 1+2 installed in M125YLI.0 and M250YLI.0
• Pole mounting capability
• Manufacturer’s product warranty: 24 months

The center includes the following sockets

• 2 x Schuko 230 V 16 A
• 1 x CEE 5-pin 400 V / 6h 16 A

This product description is an automated translation of the original Finnish description.
