SOCKET-OUTLET CENTRE PJX 2113V2 125A IP44 FE/AL

The PJX socket distribution cabinet is manufactured from 2 mm stucco-finished aluminum. Typical applications for these units include squares, harbors, parking areas, camping sites, marinas, and other public areas. Four different additional accessories are available for installation, which can be performed on a ground base or alternatively on a wall or flat surface. All Vohek units are manufactured in Lieto, Finland. Features

• Rated current of the unit InA 125 A
• Rated voltage of the unit Un 400 V (50 Hz)
• Rated insulation voltage Ui=Un
• Short-time rated withstand current Icw 6 kA 1s
• Derating factor 0.7
• Enclosure rating IP44
• Impact resistance IK09
• Protection class I (protective earthing)
• Distribution system TN-S
• EMC operating environment A and B
• Curve C circuit breakers
• Residual current device type A
• Dimensions (WxHxD) 1010x410x280 mm
• Weight approximately 26 kg
• Type A residual current protection 16 A sockets 30 mA and other sockets 500 mA

The PJX socket distribution cabinets are manufactured in accordance with the European standard EN 61439-3. This product description is an automated translation of the original Finnish description.
