SOCKET-OUTLET CENTRE VOIMA 0113EM

POWER socket center is a central system designed for fixed installation in industrial workplaces and for distribution of maintenance electricity in factories. All Vohek centers are manufactured in Lieto, Finland. New in 2025! The central product range is updated and expanded. Improved installability, tightness, strength, and expandability. The enclosure is made of hot-dip galvanized steel. The door and socket panel are painted light gray, color shade RAL 7047. Thanks to the layered structure, the entire bottom of the enclosure serves as the connection space. The center comes standard with 2x50mm² branch connectors. For supply cables, the center has standard MC3 multi-lamella at the top and bottom ends. An optional separate protective roof is available as an accessory (sstl 3434767). - Rated current of the center InA 63A - Rated voltage of the center Un 400V (50Hz) - Rated insulation voltage Ui=Un - Short-time rated withstand current Icw 6kA 1s - 750VA Protective isolation transformer 230VAC - Power factor 0.7 - Enclosure rating IP44 - Impact resistance IK08 - Protection class I (protective earthing) - Distribution system TN-S - EMC operating environments A and B - Circuit breakers C-curve (standard) - Residual current device Type A - Cover color RAL 7047 - Corrosion resistance class C3 - Weight approx. 25kg The centers are manufactured in accordance with the European standard EN 61439-3. This product description is an automated translation of the original Finnish description.
