SUBCENTRE FOR WORKSITE TAKP MIDI 32 118 IP44
Product code
3434477
A compact portable distribution unit with multiple 1-phase sockets for smaller construction sites, renovations, extensions, etc. All sockets are protected by 30 mA residual current devices. Manufactured from impact-resistant durable plastic. Self-closing cover for fuses made of clear plastic. Equipped with a carrying handle and mounting holes. Sockets are protected by circuit breakers with C characteristic curve.
All Vohek distribution units are manufactured in Finland.
Features- Input: 5-pole/400V 16A socket 1 unit
- Output: 2-pole/230V Schuko Type F 8 units
- Output: 5-pole/400V 16A power socket 1 unit
- Output: 5-pole/400V 32A power socket 1 unit
- Residual current device 30mA 1 unit
- Weight: 4.0 kg
- Short-circuit withstand capacity Icc 6 kA
- Protection class IP44
Product details
Technical specifications
Product class (ETIM)Energy distributor for construction site (EC000484)
ModelMobile end-distributor
Rated voltage400 V
Rated current32 A
Connected load0 kVA
Number of CEE socket outlets (IEC 60309) 16 A / 24 V / 2P (L, N)0
Number of CEE socket outlets (IEC 60309) 16 A / 230 V / 3P (L, N, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 230 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)1
Number of CEE socket outlets (IEC 60309) 32 A / 230 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)1
Number of CEE socket outlets (IEC 60309) 63 A / 230 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 63 A / 400 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 125 A / 230 V / 4P (1, 2, 3, PE)0
Product codes
SAPCJD229
STK3434477
PLC3434477
GTIN/EAN6410034344775
Manufacturer part numberTAKP MIDI 32.118
Vendor material number3434477
Basic information
Package measurements (L x W x H)110 x 320 x 410 mm
Package volume14.432 l
Package weight4 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121308
BrandVOHEK
VendorVOHEK OY
The country of origin stated by the supplierFinland
