SUBCENTRE FOR WORKSITE TAKP MINI 16 024 IP44
Product code
3434470
Smaller portable center suitable for smaller work sites. All outlets protected with 30mA residual current devices. Manufactured from impact-resistant durable plastic. Self-closing plastic cover for fuses. Equipped with a carrying handle and mounting holes.
All Vohek centers are manufactured in Finland.
Features
- Input: 5-pin/400V 16A socket 1 piece
- Output: 2-pin/230V Schuko Type F outlets 4 pieces
- Output: 5-pin/400V 16A power sockets 2 pieces
- Residual current device 30mA 1 piece
- Weight: 2.7 kg
- Short-circuit withstand capacity Icc 6 kA
- Protection class IP44
Product details
Technical specifications
Product class (ETIM)Energy distributor for construction site (EC000484)
ModelDistributor cabinet
Rated voltage400 V
Rated current16 A
Connected load0 kVA
Number of CEE socket outlets (IEC 60309) 16 A / 24 V / 2P (L, N)0
Number of CEE socket outlets (IEC 60309) 16 A / 230 V / 3P (L, N, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 230 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)2
Number of CEE socket outlets (IEC 60309) 32 A / 230 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 63 A / 230 V / 4P (1, 2, 3, PE)0
Number of CEE socket outlets (IEC 60309) 63 A / 400 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 125 A / 230 V / 4P (1, 2, 3, PE)0
Product codes
SAPCJD224
STK3434470
PLC3434470
GTIN/EAN6410034344706
Manufacturer part numberTAKP MINI 16.024
Vendor material number3434470
Basic information
Package measurements (L x W x H)335 x 275 x 135 mm
Package volume12.437 l
Package weight2 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121309
BrandVOHEK
VendorVOHEK OY
The country of origin stated by the supplierFinland
